Pressure/Vacuum Relief Valve
9200Z P/V Valve with Flame Arrester, In Line
product detail
● Size Range: Available in sizes from NPS2 to NPS12, providing flexibility for various in-line applications.
● Set Pressure:
Weight loaded: Ranges from 2mbar to 69mbar, allowing for fine pressure adjustments.
Spring loaded: Offers settings from 69mbar to 999mbar for broader pressure control.
● Set Vacuum:
Weight loaded: Spans from 2mbar to 43mbar, ensuring accurate vacuum control.
Spring loaded: Ranges from 43mbar to 48mbar for customizable vacuum settings.
● Materials: Commonly available in WCB, CF8, and CF3M. Other materials can be provided upon request.
Standards Compliance
Manufactured in strict accordance with API2000, ISO28300, and ISO16852 standards, guaranteeing superior quality and performance.
Flame Arrester Details
● Flame Arrester Type:Utilizes the proven 8830/8840 series for effective flame arrestance.
● Flame Arrester Housing Materials: Options include carbon steel, SS 304, and SS 316L to suit different operating conditions.
● Flame Arrester Elements Materials:Made of SS 304 and SS 316L for excellent flame resistance.
Product Features
● Integrated Design: Combines pressure and vacuum control with flame protection in a seamless in-line configuration.
● Accurate Regulation: Ensures precise maintenance of pressure and vacuum levels for optimal system performance.
● Durable Construction: Built with high-quality materials to withstand the rigors of in-line operation.
● Efficient Flame Arrestance: Effectively prevents the spread of flames, enhancing overall safety.
Benefits
● Comprehensive Safety: Provides simultaneous protection against pressure and vacuum variations and potential flame incidents.
● Space Optimization: Compact in-line design saves valuable space within the system.
● Customization Options: Allows for selection of materials and specifications to meet specific application needs.
● Regulatory Conformance: Meets strict international standards, ensuring compliance and reliability.
